Rack Ceiling Ventilation Kit 19" 2 Fans Gray - Intellinet I-CASE FAN-2

€176.30
Tax included €144.50 excl. VAT

Ventilation kit with 2 fans for rack 19" with thermostat. Airflow 150 m³ each, power supply 230V - 50Hz, dimensions 410x145x45 mm, color RAL 7035 gray.



Return policy



Delivery policy



Direct contact for info



Secure Payment

Ventilation unit with 2 fans, ceiling-mountable for Rack 19 with thermostat



Fan features

  • Die-cast aluminum structure painted with powder coating RAL7035

  • Self-extinguishing reinforced fiberglass impeller UL 94V-O

  • Rotation on bronze bushing

  • Air flow: 150 m3 each fan

  • Operating temperature: -10°C + 60°C

  • Chrome-plated protection grille

  • Noise level: 43 dbA

  • Power consumption: 23W each fan

  • Power supply: 230V - 50Hz



Thermostat features

  • Adjustment range: -10°C to +80°C

  • Protection degree: IP 20

  • Electrical connection: 2 screw terminals for conductors from 0,75 mm2 to 2,5 mm2

  • Tolerance: +/- 3°K



Cabinet features

  • Steel sheet thickness 1,5 mm

  • Color RAL 7035 Gray

  • Power cable 3x1 mm2 - length 2,5 m

  • Overall dimensions: 410 x 145 x 45 mm

  • Brand
  • Reference
    I-CASE FAN-2
  • In stock
    13 Items
  • EAN13
    0766623711173
