USB-C to 2x DisplayPort MST Hub Adapter - Manhattan IADAP USBC-DP2H

€50.43
Tax included €41.30 excl. VAT

USB-C to 2 DisplayPort Adapter with 4K@30Hz support. Mirror, Extended and Video-Wall modes. Plug and Play, no external power adapter required.



Return policy



Delivery policy



Direct contact for info



Secure Payment

  • Supports 4K@30Hz resolution (Ultra-High-Definition, UHD), full 3D video and Deep Color

  • Supports Mirror, Extended, or Video-Wall mode

  • Mirror mode duplicates the computer screen onto two screens

  • Extended mode expands the workspace onto two additional screens

  • Video-wall mode uses two screens to create a single large screen; requires a graphics card that supports the Video-Wall function

  • Mac OS X supports Mirror mode up to two screens and Extended mode only on one screen

  • Plug and Play; no external power supply required



Standards and certifications

  • DP 1.2 on USB-C™

  • HDCP

  • CE

  • FCC

  • RoHS2



Connections

  • One USB type C male (input)

  • Two DisplayPort female (output)



Input/Output signal

  • Video signal input: 0.5 – 1.0 V p-p

  • DDC input signal: 5V p-p (TTL)

  • Maximum single link range: 5.4 Gbps, 3840x2160 at resolution 30 Hz

  • Video output: HDCP



Video Resolutions

  • 480i/480p/576i/576p/720p/1080i/1080p/4K@30Hz



Physical characteristics

  • Cable length: 195 mm

  • Dimensions: 60 x 49 x 12 mm

  • Weight: 49 g

  • Housing: plastic



Environmental information

  • Operating temperature: 0 – 40°C

  • Storage temperature: -20 – 60°C

  • Humidity (non-condensing): 0 – 96%



System requirements

  • Windows XP/Vista//7/8.1/10

  • DisplayPort graphics card 1.2



Package contents

  • USB-C™ to DisplayPort two-port converter adapter - MST Hub

  • User manual

  • Brand
  • Reference
    IADAP USBC-DP2H
  • In stock
    26 Items
  • EAN13
    0766623152952
