The Cat. 8.1 connector has a higher input capacity; it supports data transmission up to 40 Gbps on copper cables with braided shielded doubles. This new RJ 45 Cat. 8.1 è plug compatible with all previous categories of copper cables with braided doubles (Cat. 6 A, Cat. 6 , Cat. 5 e). It supports a maximum channel length of 30 m and a speedà of 25 Gbps and 40 Gbps. Può support data transmission speedà of Cat. 6 A to 10 Gbps and lower with a channel configuration of 100 m.
Technical specifications- Cat. 8.1 Class I according to ISO / IEC TR 11801 - 9901 - 2014 and IEC 60603 - 7
- Support PoE+
- Maximum supported power: 30 W
- Easy and fast installation without tools (T 568 A/B)
- Fully shielded, reusable zinc die-cast housing
- Robust screw-cable holder
- For rigid and flexible cable from 22 AWG to 24 AWG
- For cable with external diameter 5 - 8,5 mm
Dimensions- Length: 46,7 mm
- Width: 14,4 mm
- Height: 11,6 mm
Package contents
