• Patch Network Cable in Copper SFTP Cat 6 A Black with Led Tracing 3 m - ICOC SF 6 A- 030 -VCBK

Patch Network Cable in Copper SFTP Cat 6 A Black with Led Tracing 3 m - ICOC SF 6 A- 030 -VCBK

€19.81
Tax included €16.20 excl. VAT

RJ patch cable 45 Cat. 6 S/FTP screen with LED tracking. Length 3 meters, RJ 45 connectors with LED. Suitable for 10 Gigabit Ethernet.



Return policy



Delivery policy



Direct contact for info



Secure Payment

  • The patch cable RJ 45 Cat. 6 Shielded ICOC SF 6 A- 010 -VCBK delivers excellent performance for 10 Gigabit Ethernet applications.
  • With the help of a detector the light emitting diodes are excited in both the RJ 45 plugs of the patch cable.
  • The illuminated RJ 45 plugs facilitate the tracking of the cable path.
  • Cross section 4 x 2 x AWG 26 / 7 .
  • Fingerprint length on the cable entry.


Connectors

  • Connector type 1 connection: RJ 45 8 (8)
  • Connector type 2 connection: RJ 45 8 (8)
  • Connector type: RJ 45 LED


Technical Specifications

  • Category 6 A (TIA)
  • Pin Assignment: 1 : 1
  • Allocation: TIA/EIA 568 B
  • Type: Screenshot
  • Length Fingerprint: yes
  • Folding sleeve: applicable
  • Color antiflaps sleeve: black
  • Locking levers: yes
  • Bending radius: > 20 mm
  • Conductive Screen: Shielded Contact at 360 °
  • Cable structure: S/FTP
  • Total screen: > 65 %
  • Cable construction: 4 x 2
  • AWG-dimensions/wires for cores: 26 / 7
  • impedance: 100 ± 15 Ω
  • DC conductor strength: 165 Ω/km
  • Circuit resistance: 330 Ω/km
  • Insulation resistance: > 5000 MΩ
  • POE class: PoE sec. a IEEE 802.3 af; PoE+ sec. a IEEE 802.3 at; 4 PPOE sec. a IEEE 802.3 bt
  • Bandwidth: 500 MHz
  • Transmission: 10 Gbit
  • Connector: IEC 60603 - 7 - 51


Protection

  • Fireproof: IEC 60332 - 3
  • Halogen-free: acc. IEC 60754 - 2
  • Low smoke: acc. IEC 61034


Physical characteristics

  • Temperature range (operational): - 25 – 60 °C
  • Temperature range (installation): 0 – 50 °C
  • Conductor material: Copper
  • LSZH sheath material
  • External color of the cable: black
  • External diameter of cable: 6.2 mm
  • Length: 3 meters


Certifications

  • CE
  • RoHS


Package contents

  • Cat network cable. 6 A with LED tracking 3 meters

  • Brand
  • Reference
    ICOC SF6A-030-VCBK
  • In stock
    1 Item
  • EAN13
    4049759086749
