It is a mechanical distribution box for fiber cables, consisting of 2 half-shells largely symmetrical that form the body of the box. The upper half-shell contains a rubber gasket along the entire length of the box. The mushroom-shaped design has been specifically studied. The pressure between the two half-shells ensures waterproofness. The upper and lower parts are screwed together with stainless steel screws and nuts. The nuts are fixed in the lower part of the half-shell. A cable clamp is present near the cable entry hole in the lower part of the box. The entry grommets are rubber and conical, thus it is possible to cover a wide range of cable diameters. After splicing, the half-shells are screwed together. Then the cable glands must be turned back over the box entries and then fixed with stainless steel ties.
Technical Features
- Cable diameter: 8 - 23 mm
- Direct burial: yes
- Inputs/Outputs: 4
- Material: plastic
- Junction box: integrated
- Splice holder: crimp
- Closure type: release closure
- Protection rating: IP68
- UV resistant: Yes
- Operating temperature: -40 – 70 °C
- Suitable for number of fibers: 24
- Color: black
Dimensions
- Width: 470 mm
- Depth: 123 mm
- Height: 104 mm
Package Contents
- External Box for Splices, up to 24 Fibers, crimp I-CASE FO-OUTJ24CB
