Mini DisplayPort (Thunderbolt) Adapter to VGA Active - Manhattan IADAP MDP-VGAF 2

€18.00
Tax included €14.80 excl. VAT

Active adapter Mini DisplayPort 20 -pin male to VGA 15 -pin female. Supports resolution 1080 p@ 60 Hz.



Return policy



Delivery policy



Direct contact for info



Secure Payment

  • Connect a DisplayPort source to a VGA screen cable

  • Supports video resolutions up to 1920 x 1080 p@ 60 Hz (1080 p, Full HD); audio must be transferred separately

  • Allows you to view high definition (HD) images on monitors, projectors or other VGA display devices; supports 1080 analogue video output p

  • Active adapter (signal regeneration) exceeds the limitations of the non-DP++ (dual-mode) video/graphic card and ensures the best connection to HD monitors, projectors and many other devices

  • Integrated digital analogue converter for analogue signal output VGA

  • Fully shielded to reduce electromagnetic interference (EMI) and other sources of interference

  • Die-cast PVC Connector Covers



General information

  • Active conversion mini DP

  • Maximum single-link range: resolution 1920 x 1080 p@ 60 Hz (1080 p)

  • 32 AWG connectors

  • Resistance voltage: 300 V DC

  • Insulation resistance: 5 MOhms

  • Conductive resistance: 10 Ohm



Connections

  • A Mini DisplayPort 20 -pin male connector

  • A VGA 15 -pin Female connector

  • Nickel-plated

  • PVC connector cover

  • Assets



Physical information

  • Dimensions: 4,5 x 1,5 x 19,5 cm

  • Weight: 34 g

  • Housing: plastic



Environmental features

  • Operating temperature: 0 - 40 °C

  • Storage temperature: - 20 - 60 °C

  • Humidità (without condensation): 0 - 96 %



System requirements

  • Windows XP/Vista/ 7 / 8.1 / 10 or Mac OS 9 or higher or Linux



Standards and certifications

  • CE

  • RoHS2

  • UL 20276

  • DisplayPort 1.2 a



Package contents

  • Mini DisplayPort adapter to active VGA

  • Brand
  • Reference
    IADAP MDP-VGAF2M
  • In stock
    279 Items
  • EAN13
    0766623151504
