- Data transfer rate: 1000 Mbps
- One 1000Base-SX multimode LC duplex fiber port
- Supported distance: up to 550 m (cable 50/125) or 220 m (cable 62.5/125 µm)
- Wavelength: 850 nm
- Standard SFP form factor
- Compliant with MSA for compatibility with major switch manufacturers such as Cisco, Intellinet Network Solutions, ZyXEL, TP-Link, Ubiquiti and others (see specifications)
- Supports Digital Diagnostic Monitoring (DDM)
- Wide operating temperature range: -40 - 75°C
- Reduced electromagnetic interference thanks to metal housing
- Supports hot-plugging
Standard- IEEE 802.3z (Gigabit Fiber Optic)
General- 1000Base-SX multimode fiber 50/125 µm
- 1000Base-SX multimode fiber 62.5/125 µm
- Connector: LC duplex fiber port, 1000Base-SX
- Supported distance: 550 m
- Wavelength: 850 nm
- Fiber power budget:
- Maximum transmission power: -3 dB
- Minimum transmission power: -9 dB
- Sensitivity: -18 dB
- Power budget: 9 dB
- Design: SFP (small form factor pluggable)
CertificationsCompatible brands- Cisco, Intellinet Network Solutions, ZyXEL, TP-Link, Ubiquiti, D-Link, Edimax, Allnet, Allied Telesis, KTI Networks, LevelOne, PLANET, Tenda, TRENDnet, ZTE, Avaya, Mikrotik, Enterasys, Finisar, Dell Force10, Riverstone, Fortinet and others
Power- Required power: 3.3 V
- Power consumption: 1.0 Watt (maximum)
Dimensions- Width: 55 mm
- Depth: 13 mm
- Height: 12 mm
- Weight: 15 g
Environmental Features- Storage temperature: -40 - 85°C
- Operating temperature: -40 - 75°C
- Operating humidity: 5 – 95% RH, non-condensing
Package contents- Gigabit Fiber Optic SFP Transceiver
