Name: DisplayPort DP M to VGA F Adapter - Techly IADAP DSP-250
Brand: TECHLY
SKU: IADAP DSP-250
Price: 13.19 EUR
Availability: InStock

€13.19

Tax included

DisplayPort 20-pin male to VGA HD 15-pin female adapter. Supports resolutions up to 1920 x 1200 and 1080p. Plug and Play, compatible with Windows and Mac.

Return policy

Delivery policy

Direct contact for info

Secure Payment

Easily connect computers with DisplayPort connector to VGA monitors, projectors, etc.
Provides a high quality digital video signal - ideal for extending the life of old equipment equipped with VGA connection
Supports color depth, high bandwidth applications at 10.8 Gbps and resolutions up to 1080p on 1920 x 1200 (WUXGA) monitors
Plug and Play
Compatible with Windows and Mac

Standards and certifications:

FCC
CE
DisplayPort 1.1

Contacts:

(1) DisplayPort 20-pin male
(1) HD 15-pin female
Nickel contacts

General information:

Power: +3.3 V (from DisplayPort source)
Measured power: Active, 1.4 W; standby, 100 mW
Automatic destination detection (based on DDC return) and standby mode
EDID pre-fetch (VGA EDID conversion)

Signal Input/Output:

Single link range, 1920 x 1200, 1080p (maximum)
Supports VGA video, 1920 x 1200 (maximum)
Analog video output (RGB): 700 mV swing
Video resolution up to 1920 x 1200 (WUXGA-R), 60 Hz, 8 bpc; 154 MHz
Supports bandwidth up to 10.8 Gbps
Supports color depth, 8-bit and 10-bit
Supports auxiliary channel, 1 Mbps
Signal one lane, one direction for four-way connection
Video bandwidth amplifier, 8 bpc / 10 bpc

Operating frequency:

Frequency, 154 MHz / 144 MHz
Vertical frequency, 60 Hz

General information:

Temperature: Operating, from 0° to 70° C; storage, from -10° to 80° C
Humidity: Operating, from 10% to 85% RH (non-condensing); storage, from 5% to 90% RH (non-condensing)

Physical information:
