Wireless Access Point / Router PoE Gigabit dual-band AC 1300 - Intellinet I-WL-ACCESS- 1300

€135.98
Tax included €111.50 excl. VAT

Access point/router PoE Gigabit dual-band AC 1300 with IEEE 802.11 technology ac Wave 2 and MU-MIMO. Provides up to 867 Mbps on the band 5 -GHz and 450 Mbps on the band 2.4 -GHz, with three Gigabit ports and PoE IEEE 802.3 support af.



Return policy



Delivery policy



Direct contact for info



Secure Payment

  • Ultra fast data transfer up to 1.3 Gbps in dual-band simultaneous operation

  • Compatible with Intellinet Wireless Access Point Management Controller (see model # 525749)

  • Modern IEEE 802.11 ac Wave 2 technology for a significant increase in network efficiency

  • Provides up to 867 Mbps on 5 -GHz and 450 Mbps band on 2.4 -GHz band

  • MU-MIMO technology to increase speedà and throughput for multiple devices simultaneously

  • Wireless Client Isolation for additional security

  • Three Gigabit network prote for super fast cable connections

  • Supports modalità: Access point, Router, WDS

  • Automatic search of the last congested WLAN channel for optimal performance

  • Supports WEP, WPA/WPA 2 , WPA-PSK/WPA 2 -PSK data encryption

  • Supports Qos (Quality of Service) bandwidth management

  • Easy installation via a Web user interface or via Intellinet Wireless Access Point Management Controller (see model # 525749)

  • Enabled PoE; not è need to install near a traditional power source

  • PoE powered periferica compliant with IEEE 802.3 af standard with a PoE port (PD)

  • Includes power supply and mounting brackets for optional wall or ceiling installation

  • Updated Firmware



Standard

  • IEEE 802.11 ac Wave 2 (867 Mbps Wireless LAN)

  • IEEE 802.11 n (450 Mbps Wireless LAN)

  • IEEE 802.11 a (54 Mbps Wireless LAN)

  • IEEE 802.11 g (54 Mbps Wireless LAN)

  • IEEE 802.3 u (100 Base-TX Fast Ethernet)

  • IEEE 802.3 i (10 BASE-T)

  • IEEE 802.3 ab (Twistate Gigabit pairs network)

  • IEEE 802.3 af (Power over Ethernet 802.3 at Type 1)

  • IEEE 802.3 at (Power over Ethernet 802.3 at Type 2)



General information

  • Chipset: Qualcomm QCA 8337 Gigabit Ethernet

  • LAN port: 2 x RJ 45 10 / 100 / 1000 Mbps data

  • WAN door: 1 x RJ 45 10 / 100 / 1000 Mbps data port and power input port (PD PoE port)

  • USB port: 1 x USB-A for save/backup configuration and firmware updates

  • Flash memory: 16 MB

  • RAM memory: 128 MB DDR 2

  • Certifications: FCC, CE, RoHS



Wireless 5 GHz

  • Chipset: Qualcomm QCA 9886

  • Velocità connection: up to 867 Mbps


Modulation:

  • IEEE 802.11 g/a: OFDM

  • IEEE 802.11 n: QPSK, BPSK, 16 -QAM, 64 -QAM

  • IEEE 802.11 ac: BPSK, QPSK, 16 -QAM, 64 -QAM, 256 -QAM


Output power:

  • ≦ 23 dBm



Wireless 2.4 GHz

  • Chipset: Qualcomm QCA 9563

  • Velocità connection: up to 450 Mbps


Modulation:

  • IEEE 802.11 g/a: OFDM

  • IEEE 802.11 n: QPSK, BPSK, 16 -QAM, 64 -QAM


Output power:

  • ≦ 24 dBm



Wireless 2.4 + 5 GHZ

  • Wireless Security:


- WEP encryption (64 / 128 bit)

- WPA/WPA 2

- WPA/WPA 2 -PSK

  • WLAN MAC address filter

  • Three antennas 2.4 GHz 3 dBi FPC incorporated; two antennas 5 GHz 3 dBi FPC incorporated



Router

  • Supported WAN connection types:


- Dynamic IP (DHCP for cable services)

- Static IP

- PPPoE (for DSL)

- PPTP

  • Protocols:


- PPPoE

- NTP

- DHCP

- DDNS

- SSH.

- Telnet.

  • Firewall:


- Port/URL/MAC filter

- DMZ (perimeter network)

- Port Forwarding

  • Wi-Fi Protected Setup (WPS)

  • Multiple SSIDs

  • System log



Feeding

  • External power supply: 12 VDC, 1.5 A

  • Through PoE PD port (IEE 802.3 at)



Physical information

  • Dimensions: 180 (L) x 180 (P) x 26 (A) mm

  • Weight: 0.318 kg

  • Operating temperature: 0 - 40 °C

  • Storage temperature: - 40 ° - 70 °C

  • Operating humidity: 10 – 90 % without condensation



Package contents

  • Managable Wireless Access Point / Router PoE Gigabit dual-band AC 1300

  • Wall or ceiling mounting kit

  • Quick guide to installation

  • Power supply

  • Brand
  • Reference
    I-WL-ACCESS-1300
  • In stock
    5 Items
  • EAN13
    0766623525831
