IP dome camera 2MP IR POE IP66 H.265 - Avtech IC-DGM2103SV

IC-DGM2103SV is a three-axis 2 Megapixel dome camera, suitable for both ceiling and wall mounting. The IR transmission distance reaches 25 meters in unlit areas and, therefore, it is ideal for use in factories or warehouses.

Cloud EaZy Networking is available to automatically connect this device to the Internet in three steps with the free mobile app, EagleEyes

The IP66 housing protects the camera from water and dust and allows installation both indoors and outdoors.



Features

• Equipped with a 1/2.8 CMOS lens


• POE (Power-over-Ethernet) support to eliminate the use of power cables and reduce installation costs (IEEE 802.3af)


• Standard ONVIF support to simplify system integration


• IR range up to 25 meters for night surveillance


• DWDR to increase image recognizability in overexposed and dark areas


• Waterproof design IP66 on the Ethernet cable connector


• Remote surveillance:



- Fully compatible with iOS and Android devices, and Internet Explorer on Windows operating system

- Free PC program, CMS Lite for monitoring 32 CH devices on Windows operating system

- Push video available on iOS and Android devices when used with Push series video NVR

• Minimum illumination: 0.001 Lux / F1.6, 0 Lux (IR LED ON)


• Shutter speed: 1/2 to 1/10,000 sec


• S/N ratio: more than 48dB (AGC OFF)


• Lens: f3.6mm / F1.6


• Viewing angle:



- 84° (Horizontal) / 45° (Vertical) / 99° (Diagonal)

• IR LED: 2 units


• Effective IR range: up to 25 meters


• IR movement: yes


• White balance: ATW


• AGC: auto


• Iris mode: AES


• PoE: yes (IEEE 802.3af)


• Protection rating: IP66


• Power supply: 12V / 1A


• Current consumption: 140mA (IR LED OFF) / 220mA (IR LED ON)


• Power consumption: PoE & PoN: 3.7W; DC adapter: 3W


• Operating temperature: -25℃~50℃



Technical specifications

• LAN port speed: 10/100 Base-T Ethernet


• Supported protocols: DDNS, PPPoE, DHCP, NTP, SNTP, TCP/IP, ICMP, SMTP, FTP, HTTP, RTP, RTSP, RTCP,IPv4, Bonjour, UPnP, DNS,UDP,IGMP, QoS, SNMP


• ONVIF compatible: yes


• Number of online users: 10



Security

• Multiple user access levels with a password


• IP address filters


• Digest authentication



Remote access

• Internet Explorer on Windows operating system


• 32CH Video Viewer on Windows and MAC operating system


• EagleEyes on mobile devices iPhone, iPad and Android



Video

• Video compression H.265 / H.264 / MJPEG


• Video resolutions 1920 x 1080 / 1280 x 720 / 720 x 480 / 352 x 240


• Frame Rate 30fps


• Multiple video streams 4 (H.265/ H.264/ MJPEG)
