CCTV Dome Camera 8MP AVColor 4 in 1 IP66 Warm Light LED - Avtech IC-DGC8206W

• CCTV dome camera from 8 Megapixel with SONY CMOS sensor 1/2.8

• Supports TVI, CVI, AHD, and CVBS video modes

• Day and night surveillance 24 hours per 24 with effective IR distance up to 25 meters

• With IP66 rated housing


Features

• SONY CMOS sensor 1/2.8

• Starlight visibility (0,001 Lux / F1,6) to provide clear and colorful images even at night

• Built-in microphone for audio recording

• WDR to increase image recognizability in overexposed and dark areas

• Day and night surveillance 24 hours out of 24 with effective IR distance up to 25 meters

• Protection rating IP66

• Camera parameters are adjustable when used with AVTECH HD CCTV DVR


Camera

• CCTV Dome Camera from 8 Megapixel

• Image sensor: 1/2.8” Sony CMOS sensor

• Supports TVI, CVI, AHD, and CVBS video modes

• Number of pixels: 3840 (H) × 2160 (V)

• Video frame rate: NTSC: 8MP@15fps / PAL: 8MP@12.5fps

• Min. Illumination: 0.001Lux / F1.6 (AGC ON), 0 Lux (IR LED ON)

• S/N ratio 62 dB

• Lens: f3.6mm/F1.6

• Viewing angle: 87.5° (Horizontal) / 44.4° (Vertical) / 104.9° (Diagonal)

• Day and night surveillance 24 hours per 24 with effective IR distance up to 25 meters
• Warm light LED: 2 LED
• IP66 for weather-resistant applications
• Power supply (± 10%) DC12V

• Consumption < 5W

Physical and environmental data

• Operating temperature: -20 °C ~ 60 °C

• Operating humidity: 10% - 90% RH


Package contents

• Camera IC-DGC8206W

• Mounting screws

• User manual
