IP Camera 2MP Full HD IR Starlight IP66 motorized lenses - Avtech IC-DGM2643SV

The IC-DGM2643SV camera is a fixed IP camera also for outdoor IP66 equipped with ethernet connection also powered by Poe 802.3af. Compatible with dedicated App for IOS and Android, it allows easy configuration and thanks to motion detection it is always possible to be alerted via push notification if there are unauthorized accesses in the installation area of the camera. Thanks to Ultra Starlight visibility, it offers clear color images even at night.



Technical Specifications

• IP Camera 2Mp Full HD IR Ultra Starlight IP66


• Image sensor Image sensor CMOS 1/2.8 Lens f2.8 ~ f12mm / F1.6 ~ F2.8 (Auto Focus)


• LAN port 10/100 Based-T Ethernet


• Supported protocols DDNS, PPPoE, DHCP, NTP, SNTP, TCP/IP, ICMP, SMTP, FTP, HTTP, RTP, RTSP, RTCP, IPv4/Ipv6, Bonjour, UpnP, DNS, UDP, IGMP, QoS, SNMP


• ONVIF compatible YES (Profile S)


• Security Multiple user access levels with password / IP address filter / Digest authentication


• Remote access via Internet Explorer on Windows


• Remote access via CMS Lite software for Windows


• Remote access via dedicated EagleEyes App on iOS and Android mobile devices


• Number of simultaneous online users 10


• Compression H.265 / H.264 / MJPEG 1920 x 1080/1280 x 720/720 x 480/352 x 240 Frame rate 30 IPS


• Multiple video streaming 4 (H.265 / H.264 / MJPEG)


• Illumination 0.001 Lux / F1.6 (Wide) ~ F2.8 (Tele), 0 Lux (IR LED ON)


• Shutter speed from 1/2 to 1 / 10.000 sec / S/N ratio More than 48 dB (AGC off)


• Lens: motorized f2.8 ~ f12mm / F1.6 ~ F2.8 (auto focus)


• Viewing angle:



Wide: 87° (Horizontal) / 50° (Vertical) / 93° (Diagonal)

Tele: 33° (Horizontal) / 19° (Vertical) / 37° (Diagonal)

• IR mode with white LEDs 2 units with effective distance up to 50 meters Ultra Starlight


• ATW white balance


• AGC Auto / IRIS mode AES / Sharpness / DWDR


• EaZy Networking / Event notification FTP / Email / SMS


• Pan / Tilt / Digital zoom / Motion detection


• Privacy mask / Vertical display mode / Defog


• IP rating 66 for outdoor installation



Physical and Environmental Data

• Startup temperature 0 ℃ ~ 50 ℃


• Operating temperature -25 ℃ ~ 50 ℃


• Operating humidity 90% or less relative humidity


• Power supply (± 10%) DC12V (optional power adapter)


• POE power (IEEE 802.3af)


• Current consumption (± 10%) 140mA (LED OFF); 420mA (LED ON)


• Power consumption (± 10%) 6.9W (PoE / PoN) ; 5.5W (DC Adapter)


• Net weight (kg) 0,94


• CE certification



Package contents

• IP Dome Camera IC-DGM2643SV


• Waterproof mounting kit


• Quick Guide
