IP Dome Camera H.265 2MP Starlight Motorized Lens - Avtech IC-DGM2443

• Camera equipped with motorized varifocal lens, focal length and focus adjustment can be done remotely


• Free P2P Cloud EaZy network



-- Cloud EaZy Networking available to connect this device to the Internet automatically in three steps with our free mobile app, EagleEyes

-- The Buddy function to share device access allowed to other people

-- Report device access/exit notifications

• Starlight visibility to offer sharpness and color to images even at night


• POE (Power-over-Ethernet) support to eliminate the use of power cables and reduce installation costs


• Supported ONVIF standard to simplify system integration


• DWDR to increase image recognizability in overexposed and dark areas


• Vertical viewing mode supported to monitor long and narrow areas such as corridors


• Remote surveillance:



-- Fully compatible with iOS and Android devices and Internet Explorer on Windows operating system

-- Free PC program, CMS Lite, for monitoring 32CH devices on Windows operating system



Network

• LAN port


• LAN speed: 10/100 Based-T Ethernet


• Supported protocols: DDNS, PPPoE, DHCP, NTP, SNTP, TCP/IP, ICMP, SMTP, FTP, HTTP, RTP, RTSP, RTCP, IPv4/Ipv6, Bonjour, UpnP, DNS, UDP, IGMP, QoS, SNMP


• ONVIF Profile S compatible


• Number of online users: 10


• Safety:



(1) Multiple user access levels with password

(2) IP address filtering

(3) Digest authentication

• Remote access:



(1) Internet Explorer on Windows operating system

(2) CMS Lite, CMS 32CH software for Windows operating system

(3) EagleEyes on iOS and Android mobile devices



Video

• Network compression H.265/H.264/MJPEG


• Video resolution 1920 x 1080 / 1280 x 720 / 704 x 480 / 352 x 240


• Frame rate 30 fps


• Multiple video streaming 4 (H.265 / H.264 / MJPEG)



General features

• Image sensor: CMOS 1/2,8


• Minimum illumination 0,001 Lux / F1.6 (Wide) ~ F2.8 (Tele), 0 Lux (LED IR on)


• Shutter speed from 1/2 to 1/10.000 sec


• S/N ratio More than 48dB (AGC off)


• Motorized lens f2.8 ~ f12mm / F1.6 ~ F2.8 (autofocus)


• Wide viewing angle:



- 87° (Horizontal) / 50° (Vertical) / 93° (Diagonal)

- Telephoto: 33° (Horizontal) / 19° (Vertical) / 37° (Diagonal)

• IR LED: 4 units


• Effective IR distance up to 50 meters


• With IR movement


• Smart light control


• ATW white balance


• Automatic AGC


• IRIS AES mode


• Sharpness


• DWDR


• PoE IEEE 802.3af


• With vertical display mode


• IP66 protection



Environmental features

• Operating temperature -25 ~ 50 °C


• Operating humidity: 90% or less



Certifications

• CE



Package contents

• Camera IC-DGM2443


• User manual
