- Compatible with HPE (Hewlett Packard Enterprise) switches and routers
- Data transfer rate: 1000 Mbps
- One 1000Base-SX multimode LC duplex fiber port
- Supported distance: up to 550 m (cable 50/125) or 220 m (cable 62.5/125 µm)
- Wavelength: 850 nm
- Equivalent to HPE J4858A / J4858B / J4858C / J4858D transceiver
- Standard SFP form factor
- Reduced electromagnetic interference thanks to metal housing
- Supports hot-plugging
Standard- IEEE 802.3z (Gigabit Fiber Optic)
General- 1000Base-SX multimode fiber 50/125 µm
- 1000Base-SX multimode fiber 62.5/125 µm
- Connector: LC duplex fiber port, 1000Base-SX
- Distances:
- 550 m (50/125 µm fiber optic cable)
- 220 m (62.5/125 µm fiber optic cable)
- Wavelength: 850 nm
- Fiber power budget:
- Maximum transmission power: -3 dB
- Minimum transmission power: -8 dB
- Sensitivity: -20 dB
- Power budget: 8 dB
- Design: SFP (small form factor pluggable)
CertificationsPower- Required power: 3.3 V
- Power consumption: 1.0 Watt (maximum)
Dimensions- Width: 57 mm
- Depth: 14 mm
- Height: 12 mm
- Weight: 20 g
Environmental- Operating temperature: 0 – 70°C
- Typical operating temperature: 34,8 ° C
- Operating humidity: 5 – 95% RH, non-condensing
- Storage temperature: -40 – 85°C
Package contents- Gigabit Fiber Optic SFP Transceiver
