CCTV Dome IR Quadbrid Camera 5MP Ceiling Motorized Lens - Avtech IC-DGC5446

€134.99
Tax included €110.70 excl. VAT

IR quadbrid dome camera 5 MP with CMOS sensor 1/2,5", output TVI/CVI/AHD/CVBS, motorized lens f2.8-12 mm, IR up to 50 m, IP66, built-in microphone.



Return policy



Delivery policy



Direct contact for info



Secure Payment

  • CMOS sensor 1/2,5 with 5 MP video output

  • Low light sensitivity of 0,1 Lux / F1,4 ~ F2,8, 0 Lux (IR LED on)

  • Quadbrid video output with TVI, CVI, AHD and CVBS to meet different customer needs

  • DWDR to increase image recognizability in overexposed and dark areas

  • Day and night surveillance 24 hours per 24 days with effective IR distance up to 50 meters

  • IP66 for weather-resistant applications

  • Camera parameters adjustable when used with AVTECH HD CCTV DVR

  • Built-in microphone for audio recording



Technical specifications

  • Video modes: TVI, CVI, AHD and CVBS switchable

  • Image sensor: CMOS Pick-up Element 1/2,5”

  • Number of pixels: 2560 (H) x 1920 (V)

  • Video frame rate 5 MP at 20 fps

  • Min. Illumination 0.1 Lux / F1.4 (Wide)~F2.8 (Tele), 0 Lux (IR LED on)

  • S/N ratio More than 48dB (AGC OFF)

  • Shutter speed AUTO: 1/20 sec ~ 1/20000 sec

  • Motorized lens f2.8 ~ 12mm / F1.4 ~ F2.8

  • Wide angle lens: 113,5° (horizontal) / 59,3° (vertical) / 137° (diagonal)

  • Telephoto lens: 33,4° (horizontal) / 18,7° (vertical) / 38,2° (diagonal)

  • IR LED 4 units

  • Effective IR distance Up to 50 meters

  • IR switch

  • Day and night mode

  • Built-in audio microphone

  • Noise reduction

  • IRIS AES mode

  • White balance AUTO

  • AGC AUTO

  • BLC

  • DWDR

  • Protection rating IP66

  • Power supply (±10%) DC12V / 1A

  • Current consumption (±10%) 120mA (IR LED OFF); 340 mA (IR LED ON)

  • Net weight (kg) 0,75

  • Junction box for optional peripherals (AVA456-BKT / AVA456-HBKT)



Environmental features

  • Operating temperature -20 ~ 40 °C

  • Operating humidity: 90% or less



Certifications

  • CE



Package contents

  • CCTV Camera IC-DGC5446

  • User manual

  • Brand
  • Reference
    IC-DGC5446
  • In stock
    3 Items
  • EAN13
    4713218634511
