Splitter Audio HDMI 2.1 1 in 2 out 8 K@ 60 Hz SPDIF 3.5 mm - Techly IDATA HDMI- 8 K 2 A

IDATA HDMI- 8 K 2 A è an audio splitter HDMI 2.1 1 in 2 out can help you connect a signal source device to a display device. At the same time, it can also synchronize and separate the digital audio in the HDMI signal to the SPDIF fiber output or emit stereo analog audio to 2 channels after the internal audio DAC conversion.

It supports digital audio formats such as Dolby Digital AC- 3 , DTS and LPCM and can ` transmit to DVD players, Blu-ray players, HDMI high definition output terminals.

Ideal for the distribution of information, presentations in conference rooms, digital environments and business environments, training places on various entertainment devices such as network players, decoder, PS 2 , PS 3 , Xbox 360 and PC.



Features

• Maximum resolution: 8 K@ 60 Hz/ 30 420 / 4 K 120


• Maximum bandwidth: 40 Gbps


• HDMI Frequency Support: LPCM up to 7.1 192 KHz 24 bit, Dolby Digital, Dolby Digital Plus, Dolby MAT, Dolby TrueHD, Dolby Atmos (all formats), Dolby



AC- 4 , DTS Digital, DTS Discreet, DTS Express, DTS HiRes Audio, DTS Master Audio, DTS:X

• The output format SPDIF TOSLINK: LPCM up to 5.1 96 KHz 24 Bit, Dolby Digitale 5.1 , high resolution audio DTS


• Output format RCA stereo: PCM 2 CH


• HDCP version: HDCP 2.3 è backcompatible


• HDMI version: HDMI 2.1 è backcompatible


• Supports HDMI ARC return function. When HDMI ARC è is input, the analog output is not è supported; è supported only digital audio output


• Supports HDMI video output. Supports audio fiber optic output and stereo headset from 3,5 mm at the same time



Technical specifications

• Bandwidth: 40 Gbps


• Input: 1 x HDMI


• Outputs: 2 x HDMI; 1 x SPDIF; 1 x audio 3.5 mm


• Supported HDMI frequencies: LPCM up to 7.1 192 KHz 24 bit, Dolby Digital, Dolby Digital Plus, Dolby MAT, Dolby TrueHD, Dolby Atmos (all formats), Dolby



AC- 4 , Digital DTS, Discreet DTS, DTS Express, DTS HiRes Audio, DTS Master Audio, DTS:X

• Optical audio format: LPCM 2 CH and DTS 2 ~ 5.1 CH


• Frequency output 3,5 mm: PCM 2.0 CH


• HDCP version: HDCP 2.3 back compatible


• HDMI version: HDMI 2.1 back compatible


• Power supply: 5 V 2 A



Dimensions

• Width: 180 mm


• Depthà: 75 mm


• Height: 26 mm



Environmental features

• Operating temperature: 0 / 40 °C


• Storage temperature: - 20 / 60 °C



Package contents

• Splitter HDMI 1 in 2 out


• USB Power Supply


• User manual
