Switch 4 x 1 HDMI 2.1 8 K 3 D with Optic SPDIF - Techly IDATA HDMI- 2148 KT

IDATA HDMI- 2148 KT è a switch 8 K 4 -in- 1 -out. Supports 4 HDMI signal inputs and 1 HDMI signal output, the maximum resolution è 8 K at 60 Hz and è back-compatible.

A variety of control methods (IR remote control and RS- 232 switch) can easily switch the contents of the 4 HDMI signal sources on the display. The product è widely used in security monitoring, multimedia entertainment, transmissions, control centers, etc.



Features

• Supports 4 HDMI inputs and 1 HDMI output


• Compatible with HDMI V 2.1 devices


• Supports HD resolutions up to 8 k@ 60 Hz and compatible with previous versions


• Supports uncompressed audio, such as LPCM 7.1 CH. Supports HDR 10 +, Dolby Vision, HLG, YUV 4 : 4 : 4


• Multiple switching mode (s): IR remote control, RS- 232 control


• Supports additional digital audio output on S/PDIF port


• Firmware can be updated via Micro USB


• Supports EDID and HDMI 3 D, VRR (free sync, G-sync)


• Lightning protection, overvoltage protection, ESD protection



Technical specifications

• HDMI resolution: 7680x4320@24/25/30/50/60Hz, 4096x2160@24/25/30/50/60/100/120Hz, 3840x2160@24/25/30/50/60/100/120Hz, 3440x1600@60Hz, 3440x1440@60Hz、2560x1600@60Hz, 2560x1440@60/100/120Hz, 2560x1080@60Hz, 2048x1080@60Hz, 1920x1440@60/100/120Hz, 1080p@50/60/100/120Hz, 1080i@50/60Hz, 720p@50/60Hz


• HDMI 2.1


• HDCP 2.3


• Maximum transmission speed: 48 Gbps


• Maximum working current: 5 V/ 1 A


• Power consumption: < 2W



Dimensions

• Width: 160.0 mm


• Depthà: 58.0 mm


• Height: 20.6 mm



Environmental features

• Operating temperature: - 20 / 60 °C


• Storage temperature: - 30 / 70 °C


• Umidità operating: 0 to 90 % RH



Package contents

• 1 x Switch HDMI 4 X 1


• 1 x Power supply 5 V/ 1 A


• 1 x Remote control


• 1 x Grounding Screws


• 1 x Clamper


• 1 x User guide
