CCTV Bullet Camera 2Mp 4-in-1 IP67 - Avtech IC-DGC2105

The IC-DGC2105 camera is a fixed CCTV camera also for outdoor use IP67
Thanks to Ultra Starlight visibility it offers clear color images even at night.

Features

• CMOS sensor 1/2,9" with video output of 2 MP

• Video output with TVI, CVI, AHD and CVBS to meet different customer needs

• Low light sensitivity of 0,01 Lux / F1.6, 0Lux (IR LED on)

• Built-in microphone for audio recording

• D-WDR to increase image recognizability in overexposed and dark areas

• Day and night surveillance 24 hours per 24 with effective IR distance up to 25 meters

• IP67 for weather-resistant applications

• Adjustable camera parameters when used with AVTECH HD CCTV DVR


Technical specifications

• CCTV IR Ceiling/Wall Camera 2 Megapixel

• Supports TVI, CVI, AHD, and CVBS video modes

• CMOS image sensor 1/2,9

• Number of pixels 1920 (H) × 1080 (V)

• Min. Illumination 0.01Lux / F1.6, 0 Lux (IR LED ON)
• S/N ratio: 62 dB

• Lens f3.6mm/F1.6

• Lens angle 83.8° (Horizontal) / 42.7° (Vertical) / 100.1° (Diagonal)

• IR LED with 18 units with effective IR distance up to 25 meters

• Equipped with IR movement, day and night mode, noise reduction

• IP rating IP67 for outdoor installation


Physical and environmental data

• Operating temperature: -20 °C ~ 60 °C

• Operational humidity: 90% or less relative humidity

• Power supply (± 10%) DC12V


Package contents

• Camera IC-DGC2105ATS

• Mounting screws

• User manual
