CCTV Dome Camera Quadbrid 5MP IR - Avtech IC-DGC5005

€45.64
Tax included €37.40 excl. VAT

CCTV Dome Camera with 5 MP sensor and quadbrid output (TVI, AHD, CVI, CVBS). IR range up to 25 meters, built-in microphone and DWDR for clear images in backlight.



Return policy



Delivery policy



Direct contact for info



Secure Payment

Features

  • CMOS sensor 1/2,5\" with video output 5 MP

  • Quadbrid video output with TVI, AHD, CVI and CVBS

  • Built-in microphone for audio recording

  • DWDR to increase image recognizability in overexposed and dark areas

  • Day and night surveillance 24 hours per 24 with effective IR distance up to 25 meters

  • Camera parameters adjustable when used with DVR CCTV HD



Technical specifications

  • Video mode TVI (default) / AHD / CVI / CVBS

  • CMOS image sensor 1/2,5”

  • Number of pixels 2560 (H) x 1920 (V)

  • Video frame rate 5 MP at 20 fps

  • Minimum illumination 0,01 Lux / F1,8, 0 Lux (IR LED on)

  • S/N ratio Greater than 48 dB (AGC OFF)

  • Shutter speed 1/30 (1/25) sec ~ 1/ 60000 (1/ 50000) sec

  • Lens f3,6 mm/F1,8

  • Lens angle 96° (horizontal) / 50° (vertical) / 116° (diagonal)

  • IR LED 12 units

  • Effective IR distance Up to 25 meters

  • IR shift

  • Day and night mode

  • IRIS AES mode

  • White balance AUTO/MANUAL

  • AGC HIGH/MEDIUM/LOW

  • Sharpness

  • BLC

  • HLC

  • Noise reduction

  • Anti-flicker

  • DWDR

  • Built-in audio microphone

  • Power supply (±10%) DC12V / 1A

  • Current consumption (±10%) 50 mA (IR LED OFF); 199 mA (IR LED ON)



Environmental features

  • Operating temperature 0°C ~ 50°C

  • Operating humidity 90% or less relative humidity



Package contents

  • Camera IC-DGC5005

  • User manual

  • Brand
  • Reference
    IC-DGC5005
  • In stock
    3 Items
  • EAN13
    4713218634481
