IP Bullet Camera PoE IR 5MP H.265 IP67 mot. 2.8-12mm AI - Avtech IC-DGM5545A

• Camera equipped with a motorized lens from f2,8 ~ 12 mm

• AI-based human detection supported to avoid false detection alarms

• Supported ONVIF standard to simplify system integration

• POE (Power-over-Ethernet) support to eliminate power cables and reduce installation costs

• Built-in microphone for audio recording

• Effective IR range up to 30 meters for night surveillance

• DWDR to increase image recognizability in overexposed and dark areas

• Remote surveillance

• Compatible with Internet Explorer 6 and later, Microsoft Edge and Google Chrome


Technical specifications

• CMOS image sensor 1/3"

• Maximum resolution 2592 x 1944

• Lens f2,8 ~ 12 mm / F1,6 ~ F2,2

• Telephoto viewing angle 40° ~ Wide angle 117° (diagonal)

• Minimum illumination 0,01 Lux (IR LED off), 0 Lux (IR LED on)

• Shutter speed AUTO

• IR LED of 20 units

• Effective IR distance Up to 30 meters

• Day/Night

• WDR Mode: DWDR

• RTC (real-time clock)


Video

• H265 / H.264 compression

• Video resolution: Main stream 5MP (2592x1944) / 4MP (2560x1440) / 3MP (2304x1296) / 2MP (1080P) / 720P; Secondary stream D1/VGA/640x360/480x360/CIF
• Frame rate 5 MP at 25 FPS
• Video profile High profile/Main profile/Baseline profile

• Multiple video streaming 2 streams

• Bitrate control 32Kbps - 8Mbps, VBR/CBR

• Image enhancement DWDR/HLC/2D DNR/3D DNR/AWB

• Day/Night switching Auto/Color/(B/N)/Timer

• Forced anti-flicker

• Auto/Manual white balance

• Image orientation Flip/Mirror

• Privacy mask

• Text overlay

• Configurable OSD title position/font size/text; text input (English and Chinese characters) and image upload (BMP) supported


Audio

• Built-in microphone

• Encoding G.711-U / G.711-A

• Audio adjustment


Alarm and event

• Human detection mode

• Detection program

• Motion detection area 1x1, 2x2, 3x2, 3x3, 4x3, 4x4, 8x8, 16x16, 22x18


Network

• LAN port RJ45 connector x 1/4KV surge-proof

• Ethernet LAN speed based on T from 100 Mbps

• Supported protocols HTTP/RTSP/FTP/SMTP/DHCP/NTP/NFS/RTMP

• ONVIF compatible Compatible with Onvif 17.06

• Number of online users 6

• Remote access Internet Explorer 6 and later (recommended), Microsoft Edge and Google Chrome


General

• Web interface language: English, Traditional Chinese, Simplified Chinese, Russian, German, Italian, Turkish, Korean

• Operating temperature -30°C ~ 60°C

• Operating humidity 10%-90%RH

• POE IEEE 802.3af

• Power supply (±10%) PoE / DC12V

• Power consumption (±10%) < 8 W

• Net weight (kg) 1,05

• IP67 housing

Minimum web browsing requirements

• Intel Core i3 or higher, or equivalent AMD

• 2 GB RAM

• AGP graphics card, Direct Draw, 32 MB RAM

• Windows 10, Windows 8, Windows 7, DirectX 9.0 or later

• Internet Explorer 6 and later (recommended), Microsoft Edge and Google Chrome


Package contents

• Motorized IP Bullet Camera PoE IR H.265 5MP IP67 AI-based Detection IC-DGM5545A

• User manual
