Inseritor Audio HDMI 4 K 2 K - Techly IDATA HDMI-AI 4 K

This HDMI 4 K 2 K audio plug-in allows you to insert an external audio signal into an HDMI or DVI source (with adapter from DVI to HDMI). The unità allows you to insert stereo or multichannel surround audio signals to offer users the possibilityà to select audio formats while extending the HDMI signal. In addition, both input and HDMI output support HD resolution up to 3 D and 4 K 2 K for a complete audio experience compared to video and audio synchronization.



Features

• Conforms with HDMI, HDCP 1.2 and DVI 1.0


• Supports sampling frequency for HDMI audio up to 192 kHz


• Supports sampling frequency for S/PDIF optical audio up to 192 kHz


• Supports external, digital or analogue HDMI audio signal embedded in HDMI signal


• Supports HDMI high-bit-rate (HBR) audio


• Supports DVI conversion with adapter from DVI to HDMI


• Supports CEC bypass


• Supports 4 K 2 K resolution and 3 D signal



Specifications

• Video bandwidth: 300 Mbps / 10.2 Gbps


• Entry Doors



- 1 x HDMI,

- 1 x Optics (Digital Audio),

- 1 x jack 3.5 mm (L/R)

• Output port: 1 x HDMI


• Sampling frequency Audio HDMI: up to 192 kHz


• Sampling frequency Optical audio S/PDIF: up to 192 kHz


• HDMI audio format: LPCM 2 / 5.1 / 7.1 CH, DTS 2 - 5.1 CH, TrueHD and DTS-HD Master Audio


• Optical audio format: LPCM 2 CH and DTS 2 ~ 5.1 CH


• Audio format L/R: Analog Stereo 2 CH


• Power supply: 5 V / DC


• Dimensions (mm): 95 x 83 x 24 mm


• Operating temperature: 0 °C~ 40 °C


• Storage temperature: - 20 °C~ 60 °C



Package contents

• HDMI 4 K 2 K audio insert


• Power supply


• Education manual
