- Compatible with HPE (Hewlett Packard Enterprise) switches and routers
- Data transfer speed: 10 Gbps
- One port 10GBase-SR multimode Optical Fiber LC duplex
- Fiber supported distance: up to 300m
- Wavelength: 850 nm
- Equivalent to HPE J9150A / J9150D / JD092A / JD092B transceiver
- Standard SFP+ form factor
- Supports Digital Diagnostic Monitoring (DDM)
- Reduced electromagnetic interference thanks to metal housing
- Supports hot-plugging
Standard- IEEE 802.3z (Gigabit Fiber Optic)
- IEEE 802.3ae (Fiber optic 10 Gigabit Ethernet)
General- Supports multimode fiber optic 10GBase-SR
- Connection: LC duplex fiber optic port
- Distance:
- 300m with 50/125 µm cable on 2000 MHz-km
- 33m with 62.5/125 cable on 200 MHz-km
- Wavelength: 850 nm
- Fiber optic power:
- Maximum TX power: -1 dB
- Minimum TX power: -6 dB
- Sensitivity: -10 dB
- Power budget: 4 dB
- Design: SFP+ (enhanced small form-factor pluggable)
- SFF-8472 Diagnostic Monitoring Interface for Optical Transceivers
- Certifications: FCC Class A, CE, IEC-60825, RoHS
Power- Required power: 3.3 V
- Power consumption: 1.0 Watt (maximum)
Environmental- Dimensions (L x W x H): 57 x 14 x 12 mm
- Weight: 20 g
- Operating temperature: 0 – 70°C
- Operating humidity: 10 – 85% RH, non-condensing
- Storage temperature: -40 – 85°C
Package contents- Transceiver Module 10 Gigabit Fiber Optic SFP+
