- Compliant with MSA for compatibility with major switch manufacturers such as Cisco, Intellinet Network Solutions, ZyXEL, TP-Link, Ubiquiti and others (see specifications)
- Data transfer speed: 10 Gbps
- One port 10GBase-SR multimode Optical Fiber LC duplex
- Fiber supported distance: up to 300m
- Wavelength: 850 nm
- Equivalent to the Cisco XFP-10G-MM-SR transceiver
- Standard form factor XFP
- Reduced electromagnetic interference thanks to metal housing
- Supports hot-plugging
Standard- IEEE 802.3z (Gigabit Fiber Optic)
- IEEE 802.3ae (Fiber optic 10 Gigabit Ethernet)
General information- Supports multimode fiber optic 10GBase-SR
- Connection: LC duplex fiber optic port
- Distance:
- 300m with 50/125 µm cable on 2000 MHz-km
- 33m with 62.5/125 cable on 200 MHz-km
- Wavelength: 850 nm
- Fiber optic power:
- Maximum TX power: -1 dB
- Minimum TX power: -6 dB
- Sensitivity: -10 dB
- Design: XFP
- Certifications: FCC Class A, CE, RoHS
Power- Required power: 3.3 V
- Power consumption: 1,5 Watt (maximum)
Environmental- Dimensions (L x D x H): 78 x 16 x 11 mm (3.07 x 0.63 x 0.43 in.)
- Weight: 30 g
- Operating temperature: 0 - 70°C
- Operating humidity: 10 - 85% RH, non-condensing
- Storage temperature: -40 to 85°C
Package contents- 10 Gigabit Fiber XFP Optical Transceiver Module
