Switch True 4 K HDMI to 3 ports - Aten IDATA VS- 381 B

The True 4 K HDMI switch to 3 ports VS 381 B with automatic switching offers the exchange of 3 HDMI input sources on an HDMI display. It supports video resolutions up to True 4 K (4096 x 2160 to 60 Hz 4 : 4 : 4 ), speedà data up to 18 Gbps, HDR, 3 D, Deep Color, and lossless HD audio formats. The VS 381 B also offers modality ` between HDMI sources via the push buttons of the front panel and IR remote control to allow users to select the desired input without any problems.



The previous features offer a practical solution for auditoriums, home theater, meeting rooms, fairs, shopping centers and more.



Features

• Allows transmission of up to 3 HDMI input sources on 1 display with HDMI output


• Superior video quality – True 4 K resolution up to 4096 x 2160 / 3840 x 2160 at 60 Hz (4: 4: 4) up to 5 meters; HDR support


• HDMI (3 D, Deep Color, 4 K, HDR 10 +, Dolby Vision, HLG)


• HDCP 2.2 Conforms


• Automatic switching mode for automatic door selection


• Switch between HDMI input sources via front panel push buttons and IR remote control


• Supports IR extension


• Supports audio output to 7.1 channels


• LED indication of device status


• Plug-and-play – no software installation required



LED

• Input: 3 x HDMI inputs (Green)


• Power supply: 1 x LED power supply (Green)



Audio

• Input: 3 x HDMI Type A female (black)


• Output: 1 x HDMI Type A female (black)



Video Input

• Interfaces: 3 x HDMI Type A female (black)


• Impedance: 100 Ω


• Max. distance: maximum 5 m, 4096 x 2160 / 3840 x 2160 to 60 Hz (4 : 4 : 4 )



Video output

• Interfaces: 1 x HDMI Type A female (black)


• Impedance: 100 Ω


• Max. distance: maximum 5 m, 4096 x 2160 / 3840 x 2160 to 60 Hz (4 : 4 : 4 )



Video

• Maximum frequency of data: 18 Gbps (6 Gbps per line)


• Max. pixel clock: 600 MHz


• Conformityà: HDMI 2.0 (3 D, Deep Color, 4 K, HDR 10, Dolby Vision)


• HDCP 2.2


• Maximum resolution: 4096 x 2160 / 3840 x 2160 at 60 Hz (4: 4: 4 )



Feeding 

• 1 x CC jack connector


• Consumption: 5 V CC, 1,46 W, 6 BTU



Environmental features

• Operating temperature: 0 - 40 °C


• Storage temperature: - 20 - 60 °C


• Humidità: 0 - 80% relative humidityà without condensation



Dimensions

• Width: 7,16 cm


• Depthà: 7,90 cm


• Height: 2,55 cm



Package contents

• 1 x True switch 4 K HDMI to 3 ports VS 381 B


• 1 x LIN 5 - 02 U 1 - 701 G USB to DC power cable


• 1 x 2 XRT- 0101 G IR remote control


• 1 x 2 XRT- 0003 G IR receiver


• 1x User instructions
