PoE 4 MP Security Camera - IC-IC 7 -PRS

The PoE Shell Security Camera from 4 MP IC-IC 7 -PRS è a high performance 4 MP (2560 x 1440) engineering camera that integrates functions such as night vision infrared, motion detection, remote audio detection and PoE. It is commonly used in factories, courtyards, shops, buildings and some SME projects where contractors can use their mobile phones for remote monitoring in real time.



Many advantages with the standard PoE power supply

Comfortable: the simplified è wiring with the Ethernet cable and the power cable integrated in one.

Sure: weak power construction greatly improves safety.

Cheap: does not require power cable, power adapter or accessories for power sockets.

Constant: Simple accessories make the line more stable and troubleshooting easier.



Connecting to the Network VCR (NVR) PoE for small networks

Equipped with a high-performance CMOS image sensor, the camera can ` display UHD images from 4 MP (2560 * 1440) with more ù monitoring details.

For monitoring scenarios as medium and large as markets, industrial areas and parking spaces, è can connect the camera to the PoE switch for networking.

For monitoring scenarios as small as small shops and restaurants. Monitoring requirements can be met simply by connecting the camera to the NVR PoE.



Connecting to PoE switch for medium and large networks

For medium and large monitoring scenarios such as markets, industrial areas and parking spaces, è can connect the camera to the PoE switch for networking.



Clear monitoring details from UHD images from 4 MP

Equipped with a high-performance CMOS image sensor, the camera can ` display UHD images from 4 MP (2560 * 1440) with more ù monitoring details.



Starlight night vision with good performance in poor lighting conditions

With night vision with starlight or rate from the wide aperture lens and highly sensitive sensor, the light-sensitive è camera is more ù than common cameras and can ò display fewer images than common infrared cameras.



Audio pickup over 5 m, audio and video synchronization

With a highly sensitive built-in microphone that supports remote audio collection over 5 m, the camera can ò sync audio and video.



Compatible with NVR of other brands with ONVIF

It can be used with traditional NVRs on the market, with high compatibility.



Remote control

The camera supports remote control on the app to view monitoring in real time.

Once the camera detects an abnormal event, invierà remote alarm notification.



H. 265 encoding technology for fluid video and efficient data storage

Compared to H. 264 , the new generation H. 265 saves the 50 % of the video data size, which makes it more ù smooth videos with saved bandwidth and data storage space.



Wall and ceiling mounting

The camera can be mounted to the wall or ceiling, quite flexible and convenient.



Technical specifications

• Ethernet doors: 1 Ethernet port RJ 45 100 M on the tailline


• Lenses: 4 mm F 2.2


• Dimensions: 106.8 x 90.5 mm


• Resolution: 2560 * 1440


• Standard coding: H. 265 /H. 264


• Modalità day and night: integrated double IR-CUT filter


• Digital noise reduction 3 D


• DWDR


• Backlight compensation


• ROI


• Audio: built-in microphone


• Network protocols: RTSP/HTTP/DHCP/DDNS/NTP/ONVIF


• Internet Network protocol IPV 4


• Infrared night vision distance: 30 m



Environmental features

• Operating temperature: - 10 to + 50 °C


• Storage temperature: - 40 to + 70 °C


• Operating Humidità 10 %- 95 %UR (without condensation)


• Storage humidità 3 % ~ 95 %UR (without condensation)



Certifications

• CE


• FCC


• RoHS



Package contents

• Security camera


• Kit wall accessories


• Quick installation guide
