PoE Security Camera 4MP - Tenda IC-IC7-PRS

The 4MP PoE dome security camera IC-IC7-PRS is a high-performance 4 MP (2560x1440) engineering camera that integrates features such as infrared night vision, motion detection, remote audio detection, and PoE. It is commonly used in factories, courtyards, shops, buildings, and some SME projects where contractors can use their mobile phones for real-time remote monitoring.



Many advantages with the standard PoE power supply

Convenient: wiring is simplified with the Ethernet cable and power cable integrated into one.

Safe: weak power construction greatly improves safety.

Cost-effective: no power cable, power adapter, or power outlet accessories required.

Stable: simple accessories make the line more stable and troubleshooting easier.



Connection to PoE Network Video Recorder (NVR) for small networks

Equipped with a high-performance CMOS image sensor, the camera can display UHD images at 4 MP (2560 * 1440) with more monitoring details.

For medium and large monitoring scenarios such as markets, industrial zones, and parking lots, the camera can be connected to a PoE switch for networking.

For monitoring scenarios as small as small shops and restaurants. Monitoring requirements can be met by simply connecting the camera to the PoE NVR.



Connection to a PoE switch for medium and large networks

For medium and large monitoring scenarios such as markets, industrial areas and parking lots, it is possible to connect the camera to the PoE switch for networking.



Clear monitoring details from 4 MP UHD images

Equipped with a high-performance CMOS image sensor, the camera can display UHD images at 4 MP (2560 * 1440) with more monitoring details.



Starlight night vision with good performance in low-light conditions

With Starlight night vision or from the wide aperture lens and highly sensitive sensor, the camera is more sensitive to light than common cameras and can display fewer images than common infrared cameras.



Audio pickup beyond 5m, audio and video synchronization

With a highly sensitive built-in microphone that supports remote audio pickup over 5m, the camera can synchronize audio and video.



Compatible with NVRs of other brands with ONVIF

It can be used with traditional NVRs on the market, characterized by high compatibility.



Remote control

The camera supports remote control via the app to view real-time monitoring.

Once the camera detects an abnormal event, it will send an alarm notification remotely.



H.265 encoding technology for smooth video and efficient data storage

Compared to H.264, the next-generation H.265 saves 50% of video data size, which makes videos smoother with the saved bandwidth and data storage space.



Wall and ceiling mounting

The camera can be mounted on wall or ceiling, quite flexible and convenient.



Technical specifications

• Ethernet ports: 1 RJ45 100M Ethernet port on the tail line


• Lens: 4mm F2.2


• Dimensions: 106.8 x 90.5 mm


• Resolution: 2560*1440


• Encoding standard: H.265/H.264


• Day and night mode: built-in dual IR-CUT filter


• Digital noise reduction 3D


• DWDR


• Backlight compensation


• ROI


• Audio: built-in microphone


• Network protocols: RTSP/HTTP/DHCP/DDNS/NTP/ONVIF


• Internet Network protocol IPV4


• Infrared night vision distance: 30m



Environmental features

• Operating temperature: -10 to +50 °C


• Storage temperature: -40 to +70 °C


• Operating humidity: 10%-95%RH (non-condensing)


• Storage humidity: 3% ~ 95%RH (non-condensing)



Certifications

• CE


• FCC


• RoHS



Package contents

• Security Camera


• Wall mounting accessory kit


• Quick installation guide
