IP Dome Camera H.265 IR 3MP IP66 AI Detection - Avtech IC-DGM3203

€69.41
Tax included €56.90 excl. VAT

IP Dome Camera with 3MP resolution (2304x1296), H.265 compression and AI people/vehicle detection to reduce false alarms. Equipped with IR up to 30m, protection rating IP66, POE support and built-in microphone.



Return policy



Delivery policy



Direct contact for info



Secure Payment

  • IP Dome Camera with IP66 housing featuring AI-based people/vehicle detection to avoid false alarms
  • Supported ONVIF standard to simplify system integration
  • POE (Power-over-Ethernet) support to eliminate power cables and reduce installation costs
  • Built-in microphone for audio recording
  • Effective IR range up to 30 meters for night surveillance
  • WDR to increase image recognizability in overexposed and dark areas
  • Remote surveillance
  • Compatible with Internet Explorer 6 and later, Microsoft Edge and Google Chrome


Technical specifications

  • CMOS image sensor 1/2,7”
  • Maximum resolution 2304 x 1296
  • Lens f2,8 mm / F 1.6 - f3,6 mm / F 1.6
  • Viewing angle 112° - 99° (diagonal)
  • Minimum illumination 0,01 Lux (IR LED off), 0 Lux (IR LED on)
  • Shutter speed AUTO, 1/25s - 1/100000 s
  • LED IR: 18 units
  • Effective IR distance: up to 30 meters
  • Day/Night Mode
  • WDR Mode: DWDR
  • RTC (real-time clock)


Video

  • H265 / H.264 compression
  • Video resolution:

Main stream 3MP (2304x1296) / 2MP (1080P) / 720P / D1

Secondary stream D1/VGA/640x360/CIF

  • Frame rate 3 MP at 25 FPS / 2 MP at 30 FPS
  • Video profile: High Profile/Main Profile/Baseline Profile
  • Multiple video streaming 2 streams
  • Bitrate control 32Kbps - 8Mbps, VBR/CBR
  • Image enhancement DWDR/HLC/2D DNR/3D DNR/AWB/AGC
  • Day/Night switching Auto/Color/(B/N)/Timer
  • Forced anti-flicker
  • Auto/Manual white balance
  • Image orientation Flip/Mirror
  • Privacy mask
  • Text overlay
  • Configurable OSD title position/font size/text; text input (English and Chinese characters) and image upload (BMP) supported


Audio

  • Built-in microphone
  • Encoding G.711-U / G.711-A
  • Audio adjustment


Alarm and event

  • Detection mode: motion/human detection
  • Detection program
  • Motion detection area 1x1, 2x2, 3x2, 3x3, 4x3, 4x4, 8x8, 16x16, 22x18


Network

  • LAN port RJ45 connector x 1/4KV surge-proof
  • Ethernet LAN speed based on T from 100 Mbps
  • Supported protocols HTTP/RTSP/FTP/SMTP/DHCP/NTP/NFS/RTMP
  • Compatible with ONVIF Compatible with Onvif 17.06
  • Number of online users: 6
  • Remote access Internet Explorer 6 and later (recommended), Microsoft Edge and Google Chrome


General

  • Web interface language: English, Traditional Chinese, Simplified Chinese, Russian, German, Italian, Turkish, Korean
  • Operating temperature -30 °C ~ 60 °C
  • Operating humidity 10%-90%RH
  • POE IEEE 802.3af
  • Power supply (±10%) PoE / DC12V
  • Power consumption (±10%) < 8 W
  • Net weight (g) 274,5
  • IP66 Housing


Minimum web browsing requirements

  • Intel Core i3 or higher, or equivalent AMD
  • 2 GB RAM
  • AGP graphics card, Direct Draw, 32 MB RAM
  • Windows 11, Windows 10, Windows 8, Windows 7, DirectX 9.0 or later
  • Internet Explorer 6 and later (recommended), Microsoft Edge and Google Chrome


Package contents

  • IP Dome Camera IC-DGM3203
  • User manual

  • Brand
  • Reference
    IC-DGM3203
  • In stock
    20 Items
  • EAN13
    4713218635150
