CCTV camera Dome IR 5 MP IP 66 - Avtech IC-DGC 5204

• CCTV DOME camera with IP 66 housing

• Integrated microphone for audio recording
• Effective IR range up to 25 meters for night surveillance

• DWDR to increase image recognition in overexposed and archaic areas

• Remote surveillance

• Compatible with Internet Explorer 6 and later versions, Microsoft Edge and Google Chrome


Technical specifications

• CMOS image sensor from 1 / 2.5

• Maximum resolution 2592 x 1944

• Objective f 3,6 mm / F 1,6

• View angle 99,4 ° (horizontal) / 50,7 ° (Vertical) / 118,7 ° (Diagonal)

• Minimum lighting 0,01 Lux (LED IR off), 0 Lux (LED IR on)

• Velocità auto shutter, 1 / 25 s ~ 1 / 50000 s

• IR LED: 18 unità

• Actual IR distance: up to 25 meters

• Modelità Day/Night

• Modelità WDR


Video

• Video resolution:

TVI/AHD: 20 fps@ 2560 × 1944 P / CVI: 30 fps@ 2560 × 1440 P

• Image enhancement WDR / BLC / HLC / 2 DNR / 3 D DNR / AWB / MWB / AGC

Audio

• Built-in microphone

General

• Operating temperature - 20 °C ~ 60 °C

• Umidità 10 %- 90 %RH

• Power supply (± 10 %) PoE/DC 12 V
• Power consumption (± 10 %) < 5 W

• Net weight (g) 259

• IP 66 case

• Optional joining bracket/box AVA 126 -WHKT / AVM 552 C-HBKT / AVM 552 C-HLKT

Package contents

• CCTV camera Dome IC-DGC 5204

• User manual
