IP Bullet Camera IR H.265 3MP IP67 AI Detection - Avtech IC-DGM3103

Technical specifications

• IP Bullet Camera IR H.265 3MP

• Supports AI-based human detection to avoid false detection alarms

• Supported ONVIF standard to simplify system integration

• Supports POE (Power-over-Ethernet) to eliminate the use of power cables and reduce installation costs

• Built-in microphone for audio recording

• Effective IR range up to 30 meters for night surveillance

• DWDR to increase image recognizability in overexposed and dark areas

• Remote surveillance

• Compatible with Internet Explorer 6 and later, Microsoft Edge and Google Chrome

• CMOS image sensor SONY 1/2.7

• Maximum resolution 2304 × 1296

• Lens: f2.8 mm / F1.6 and f3.6 mm / F1.6

• Viewing angle 112° (Diagonal) and 99° (Diagonal)

• Minimum illumination 0.01 Lux (IR LED off), 0 Lux (IR LED on)

• LED IR: 18 units

• Effective IR distance: up to 30 meters

• Day/Night Vision

• WDR Mode: DWDR

• RTC (real-time clock)


Video

• H265 / H.264 compression

• Video resolution: main stream 2560 x 1440 / 2304 x 1296 / 1080P / 720P; secondary stream D1 / VGA / 640x360 / CIF
• Frame rate 3MP @ 25FPS / 2MP @ 30FPS

• Video profile: High Profile/Main Profile/Baseline Profile

• Multiple video streaming 2 streams

• Bit rate control 32Kbps - 8Mbps, VBR/CBR

• Image enhancement DWDR / HLC / 2D DNR / 3D DNR / AWB / AGC

• Day/Night switching Auto/Color/(B/N)/Timer

• Forced anti-flicker

• Auto/Manual white balance

• Image Orientation: Rotate/Mirror

• Privacy mask

• Text overlay

• Configurable OSD title position/font size/text; text input (English and Chinese characters) and image upload (BMP) supported


Audio

• Built-in microphone

• Encoding G.711-u / G.711-a

• Audio adjustment


Alarm and event

• Detection mode: Motion/Human

• Detection program

• Motion detection area 1x1, 2x2, 3x2, 3x3, 4x3, 4x4, 8x8, 16x16, 22x18


Network

• LAN port RJ45 connector x 1/4KV surge-proof

• Ethernet LAN speed based on T from 100 Mbps

• Supported protocols HTTP/RTSP/FTP/SMTP/DHCP/NTP/NFS/RTMP

• Compatible with ONVIF Compatible with Onvif 17.06

• Number of online users: 6

• Remote access: Internet Explorer 6 and above (recommended), Microsoft Edge & Google Chrome


Environmental features

• Operating temperature -30 °C ~ 60 °C

• Operating humidity 10%-90%RH


General

• POE IEEE 802.3af

• Power supply (±10%) PoE / DC12V

• Power consumption (±10%) < 8 W

• IP67 housing


Minimum web browsing requirements

• Intel core i3 or higher or AMD equivalent

• 2 GB RAM

• AGP graphics card, Direct Draw, 32 MB RAM

• Windows 10, Windows 8, Windows 7, DirectX 9.0 or later

• Internet Explorer 6 and later (recommended), Microsoft Edge and Google Chrome


Package contents

• IP Bullet Camera IR H.265 3MP IP67 AI-based detection IC-DGM3103

• User manual
