IP PoE Bullet IR Camera H.265 5MP IP67 AI Detection - Avtech IC-DGM5104S

Technical specifications

• IP Bullet IR H.265 camera, 5MP

• Supports AI-based people/vehicle detection to avoid false detection alarms

• Supported ONVIF standard to simplify system integration

• POE (Power-over-Ethernet) support to eliminate power cables and reduce installation costs

• Built-in microphone for audio recording

• Effective IR range up to 30 meters for night surveillance

• DWDR to increase image recognizability in overexposed and dark areas

• Remote surveillance

• Compatible with Internet Explorer 6 and later, Microsoft Edge and Google Chrome

• CMOS image sensor 1/2.9

• Maximum resolution 2592 x 1944

• Lens: f3.6 mm / F1.6

• Viewing angle: 96˚ (Diagonal)

• Minimum illumination 0.01 Lux (IR LED off), 0 Lux (IR LED on)

• IR LED: 4 units

• Effective IR distance: up to 30 meters

• Day/Night Vision

• WDR Mode: DWDR


Video

• H265 / H.264 compression

• Video resolution:


Main stream 5MP (2592x1944) / 4MP (2560x1440) / 3MP (2304x1296) / 2MP (1080P) / 720P
Secondary stream D1 / VGA / 640x360 / CIF

• Frame rate: 5MP @ 25FPS

• Video profile: High Profile/Main Profile/Baseline Profile

• Multiple video streaming 2 streams

• Bit rate control 32Kbps - 8Mbps, VBR/CBR

• Image enhancement: DWDR / HLC / 2D DNR / 3D DNR / AWB

• Day/Night switching Auto/Color/(B/N)/Timer

• Forced anti-flicker

• Auto/Manual white balance

• Image Orientation: Rotate/Mirror

• Privacy mask

• Text overlay

• Configurable OSD title position/font size/text; text input (English and Chinese characters) and image upload (BMP) supported


Audio

• Built-in microphone

• Encoding G.711-u / G.711-a

• Audio adjustment


Alarm and event

• Detection mode: Motion/Human

• Detection program

• Motion detection area 1x1, 2x2, 3x2, 3x3, 4x3, 4x4, 8x8, 16x16, 22x18


Network

• LAN port RJ45 connector x 1/4KV surge-proof

• LAN speed: 100 Mbps Ethernet based on T

• Supported protocols HTTP/RTSP/FTP/SMTP/DHCP/NTP/NFS/RTMP

• Compatible with ONVIF Compatible with Onvif 17.06

• Number of online users: 6

• Remote access: Internet Explorer 6 and above (recommended), Microsoft Edge & Google Chrome


Environmental features

• Operating temperature -30 °C ~ 60 °C

• Operating humidity 10%-90%RH


General

• POE: IEEE 802.3af

• Power supply (±10%): PoE / DC12V

• Power consumption (±10%): < 8 W

• Housing: IP67


Minimum web browsing requirements

• Intel core i3 or higher or AMD equivalent

• 2 GB RAM

• AGP graphics card, Direct Draw, 32 MB RAM

• Windows 10, Windows 8, Windows 7, DirectX 9.0 or later

• Internet Explorer 6 and later (recommended), Microsoft Edge and Google Chrome


Package contents

• IP PoE Bullet IR Camera IC-DGM5104S

• User manual
