Server Serial Console to 16 Doors - Aten IDATA SN- 9116 CO

The serial console SN Servers series integrates advanced technologies to provide secure access to a serial device and data center management. Available in 16 port models, serial console Servers offer remote and out-of-band serial console access to servers and network devices through a durable Telnet/SSH client and applet viewer. The serial console SN Servers work together with ATEN's Power Over the NET™ Remote Power Management Systems. Both can be used via ATEN's CC 2000 software to provide centralized access to the serial device and integrated power management. Thanks to its complete functions, the serial console Server from the SN series helps to increase productivity ` IT, improve scalability ` and reduce operating costs thanks to simple operation costs thanks to the simple and secure management of the serial console SN series. remote management of serial devices.





ATEN serial console servers are used to connect serial devices to an Ethernet network to allow access and control of applications that require it that manage industrial control, data acquisition, environmental monitoring, remote plant operations and equipment. The SN series offers different modes à operating including Real COM port, server/client TCP, server/client UDP, serial tunnel and virtual modem. Our serial console servers help transform functionality à serial devices by exploiting network access to configure and manage control of such devices from anywhere in the world via the Internet.



The Server serial console ATEN è a secure solution for remote access and control for any serial device. Rights and access privileges can be applied to 16 serial ports while password-established authentication makes it easier to manage. For security, data encryption always guarantees the protection of information and control. Registers and alarms for system events help to quickly resolve problems and limit risks. Improved security functions have been integrated to ensure complianceà internal security tasks. The simplicityà d use of the Server serial console, wide accessibilityà and manageabilityà serial services and servers allow companies to quickly integrate remote control of serial devices for consolidate operations and manage structures more effectively.



The SN series offers OOB (out-out-band) management that allows administrators to manage network devices (e.g. routers, switches, UPS) in server rooms through management networks separated from main/production networks. Therefore, in case of difficultiesà in accessing network devices via the production network, administrators can still access them via the console server. The console server offers different put-out-band accesses, e.g. direct console connection from a local computer, connecting a USB console from a laptop, a PSTN connection via the modem, or connecting a dedicated management network via the Ethernet port (LAN).



The SN series of console servers saves time and money by allowing administrators to manage their data centers from virtually anywhere by reducing travel costs and MTTR (average repair time) and ensuring maximum availability for data center services.



Features

• Accessibility and availability of the system


• Secure access to remote serial console in bandwidth and out of band


• Ethernet access in serial device band


• Intuitive user interface browser access


• Terminal-based access with menu-based user interface


• Off-band access via modem


• Incoming/Recall/Outgoing Mode Call



Serial console management

• Easy and convenient access to the serial device via a browser or Telnet/SSH client


• Port access via Telnet/SSH client and third-party clients such as PuTTY


• Direct port access from the Telnet client by passing the SN access


• Convenient port access via serial applet display from web user interface SN


• Selectable Telnet or SSH serial display


• Selectable ActiveX or Java Serial Viewer


• Full – copy/paste viewer function, log, data import, macro, message message board and transmission


• Sun Solaris Ready – Sun Break-Safe


• Warning strings


• – command filter administrators can define which commands cannot be executed by users


• Buffering data


• Several users can switch on simultaneously at the same port, up to 16 port connections


• Modelità selectable for more ù contemporary – Exclusive/Busy/Share


• Integrated with the Power Over the NET & trade; product for the connection of the door and power supply



Security

• SSH and SSL support (TLS v 1.0 / TLS v 1.1 / TLS v 1.2)


• Secure access from browser with TLS 1.2 data encryption and RSA certificates to 2048 -bit


• Configurable user permissions for port access


• Configurable group permission for port access


• Local and remote authentication and access


• Authentication of third parties through RADIUS, TACACS+, LDAP/AD and Kerberos


• IP filter and MAC filter



System Management

• System configuration via web browser, Telnet/SSH client and local console


• System log and event log


• Full log and event notification


• ATEN log server and Syslog server


• Agent SNMP


• Event notification; via SMTP email, Trap SNMP and SMS (on mobile devices)


• Backup/Restore System Configuration


• Updated Firmware


• Support multi browser – Internet Explorer, Chrome, Firefox, Safari, Opera and Mozilla


• Customizable global time zone


• NTP for time server synchronization


• DHCP for dynamic IP address assignment


• Support IPv 6


• It integrates with CC 2000 for centralized data center management



Serial Device Management

• Versatile serial usage mode – supports Real COM, TCP server, TCP client, UDP, serial tunnel and virtual modem


• SSL encryption to 128 -bit/ 256 -bit (TLS v 1.0 / TLS v 1.1 / TLS v 1.2) for Real COM, TCP server, TCP client, serial tunnel and virtual modem


• Real COM driver for Windows 2000 or later and Windows Server 2003 / 2008


• Real TTY driver for Linux


• TTY Fixed Driver for UNIX



Language

• Multilingual user graphics interface based on web – available for German, Japanese, Korean, Russian, Simplified Chinese and Traditional Chinese



Technical specifications

• Connection: 16


• Connectors:



Serial: 16 x RJ- 45 female

LAN doors: 1 x RJ- 45 female

Power supply: 1 x IEC 60320 /C 14

• Switches:



- Restore: 1 x Button cashed

- Power supply: 1 x Swing switches

• Input power load: 100 - 240 V~, 1 A, 50 / 60 Hz


• Consumption:



- 110 V/ 11,5 W;

- 220 V/ 12,2 W



LED

• Serial: 16 (green)


• 10 / 100 / 1000 Mbps: 1 (red/orange/green)


• Power supply: 1 (blue)



Environmental features

• Operating temperature: 0 - 40


• Storage temperature: - 20 - 60


• Humidità: 0 - 80% relative humidityà without condensation



Dimensions

• Width: 43,72 cm


• Depthà: 21,76 cm


• Height: 4,40 cm



Package contents

• 1 x SN 9116 Server serial console


• 1 x LIN 2 - 418 K-E 12 G power cord ( AC model)


• 1 x mounting kit


• 1 x 0 X 12 - 0017 - 301 G Lok-U-Plug


• 1 x 0 X 12 - 0017 - 401 G installation tool Lok-U-Plug


• 1 x bearing set (4 pieces)


• 1 x software CD


• 1 x user instructions
