Rack PDU power strip 1U 17x IEC-C13 + 1x IEC-C19 surge protection - ATEN I-CASE PE-0218SG

PDU 1U with 18 outlets. The compact aluminum housing ensures a slim but robust appearance while minimizing the space required for efficient work.

Thanks to the integrated surge protection module, the IT equipment connected to the PDU is well protected from sudden voltage surges; moreover, device downtime is reduced by the overcurrent protection design. Basic PDUs are custom-built for people who need an industrial-grade, easy-to-install power distribution unit for data centers, server rooms, and network distribution cabinets.



Features

• Space saving: 1U rack-mount design


• Models of IEC or NEMA sockets


• Overcurrent protection


• Surge protection


• Material: aluminum


• Works with data center server rooms and telecommunications facilities



Technical specifications

• Rated input voltage: 100 - 240 V AC


• Maximum input current 16A


• Input frequency 50 - 60 Hz


• Input connection IEC-320 C20


• Input power 3840 VA (max)


• Output type (17) IEC 320 C13- (1) IEC 320 C19


• Maximum output current (output)



C13: 10A

C19: 16A max

• Maximum output current (bank) 16A


• Maximum output current (total) 16A


• OPD (overcurrent protection device)


• Weight 1-26 kg



Dimensions

• Width: 48.20 cm


• Depth: 4.44 cm


• Height: 9.05 cm


• Network cable length: 3m (3 x 1-5 mm2)



Environmental features

• Operating temperature: 0 - 40°C


• Storage temperature: -20 - 60°C



Package contents

• 1x power distribution unit


• 1x power cable


• 1x instruction manual
