Rack PDU power strip 0U 22x IEC-C13 + 2x IEC-C19 surge protection 32A - ATEN I-CASE PE-0324SG

1U PDU with 24 outlets. The compact aluminum housing ensures a slim yet robust appearance while minimizing the space required for efficient work.

Thanks to the integrated surge protection module, the IT equipment connected to the PDU is well protected from sudden voltage surges; moreover, device downtime is reduced by the overcurrent protection design. Basic PDUs are custom-built for people who need an industrial-grade, easy-to-install power distribution unit for data centers, server rooms, and network distribution cabinets.



Features

• Space saving: design for 0U rack mounting


• Models of IEC or NEMA sockets


• Overcurrent protection


• Surge protection


• Aluminum material


• Works with data center server rooms and telecommunications facilities



Technical specifications

• Rated input voltage 100 - 240 V AC


• Maximum input current 32 A Max


• Input frequency 50 - 60 Hz


• IEC input connection 60309 32A


• Input power 7680 VA (Max)


• Output type (22) IEC 320 C13- (2) IEC 320 C19


• Maximum output current (output)



C13: 10A

C19: 16A max

• Maximum output current (bank) 16 A


• Maximum output current (total) 32 A


• OPD (overcurrent protection device)


• Weight 2-40 kg



Dimensions

• Width: 119.98 cm


• Depth: 4.44 cm


• Height: 6.00 cm


• Power cord length 3m (3 x 4 mm2)



Environmental features

• Operating temperature: 0 - 40 °C


• Storage temperature: -20 - 60 °C



Package contents

• 1x power distribution unit


• 1x L-shaped mounting bracket set


• 1x instruction manual
