Rack PDU power strip 0U 22x IEC-C13 + 2x IEC-C19 surge protection - ATEN I-CASE PE-0224SG

1U PDU with 24 outlets. The compact aluminum housing ensures a slim yet robust appearance while minimizing the space required for efficient work.

Thanks to the integrated surge protection module, the IT equipment connected to the PDU is well protected from sudden voltage surges; moreover, device downtime is reduced by the overcurrent protection design. Basic PDUs are custom-built for people who need an industrial-grade, easy-to-install power distribution unit for data centers, server rooms, and network distribution cabinets.



Features

• Space saving: design for 0U rack mounting


• Models of IEC or NEMA sockets


• Overcurrent protection


• Surge protection


• Aluminum material


• Ideal for data centers, server rooms, and telecommunications installations



Technical specifications

• Rated input voltage 100 - 240 V AC


• Maximum input current 16 A


• Input frequency 50 - 60 Hz


• Input connection IEC-320 C20


• Input power 3840 VA (max)


• Output type (22) IEC 320 C13- (2) IEC 320 C19


• Maximum output current (output)



C13: 10 A

C19: 16 A

• Maximum output current (bank) 16 A


• Maximum output current (total) 16 A


• OPD (overcurrent protection device)


• Weight 1-40 kg



Dimensions (W x D x H)

• Width: 96,68 cm


• Depth: 4,44 cm


• Height: 6,00 cm


• Network cable length 3m (3 x 1-5 mm2)



Environmental features

• Operating temperature: 0 - 40 °C


• Storage temperature: -20 - 60 °C



Package contents

• 1x power distribution unit


• 1x power cable


• 1x L-shaped mounting bracket set


• 1x instruction manual
