IP Bullet IR H.265 camera 8MP AI-based Detection - Avtech IC-DGM8109

€204.44
Tax included €167.60 excl. VAT

IP Bullet H.265 camera 8MP with SONY Starlight CMOS sensor. AI detection of people/vehicles, IR range 30m, POE support and MicroSD card up to 256 GB. Maximum resolution 3840x2160.



Return policy



Delivery policy



Direct contact for info



Secure Payment

Technical specifications

  • Starlight visibility to provide clear and colorful images even at night

  • Support for AI-based person/vehicle detection to avoid false detection alarms

  • Support for MicroSD card (up to 256 GB) for video storage

  • Supported ONVIF standard to simplify system integration

  • POE (Power-over-Ethernet) support to eliminate power cables and reduce installation costs

  • Built-in microphone for audio recording and line out support for audio transmission

  • External alarm I/O device connection

  • Effective IR range up to 30 meters for night surveillance

  • WDR to increase image recognizability in overexposed and dark areas

  • Remote surveillance

  • CMOS SONY image sensor 1/2,8

  • Maximum resolution 3840 x 2160

  • Lens f2,8mm/F1,6

  • Viewing angle 112˚ (diagonal)

  • Minimum illumination 0,001 Lux (LED IR off), 0 Lux (LED IR on)

  • Shutter speed AUTO, 1/25 ~ 1/100.000

  • IR LED 2 units

  • Effective IR distance Up to 30 meters

  • Day/Night Vision

  • WDR mode YES (120 dB)

  • RTC (real-time clock)

  • MicroSD card slot (up to 256 GB)

  • POE IEEE 802.3af

  • Power supply (±10%) PoE / DC12V

  • Power consumption (±10%) < 8 W

  • Protection rating IP67



Video

  • H265 / H.264 compression

  • Video resolution


Main stream 8MP (3840x2160) / 6MP (3072x2048) / 5MP (2592x1944) / 4MP (2560x1440) / 3MP (2304x1296) / 2MP (1080P) / 720P

Secondary stream 2MP (1080P) / 720P / 720x480 / VGA / 640x360 / 480x360 / CIF

  • Frame rate 4K (8 MP) at 30 FPS

  • Video profile High profile/Main profile/Baseline profile

  • Multiple video streaming 2 streams

  • Bit rate control 512Kbps - 12Mbps, VBR/CBR

  • Image enhancement WDR/BLC/HLC/2D DNR/3D DNR/AWB/MWB/AGC

  • Day/Night switching Auto/Color/(B/N)/Timer

  • Forced anti-flicker

  • Defogging

  • Auto/Manual white balance

  • Image Orientation: Rotate/Mirror

  • Privacy mask

  • Text overlay

  • Configurable OSD title position/font size/text; text input (English and Chinese characters) and image upload (BMP) supported



Audio

  • Built-in microphone

  • Line-out

  • Encoding G.711-u / G.711-a

  • Audio adjustment



Alarm and event

  • Alarm in

  • Alarm output

  • Detection mode Motion/Human/Vehicle/Alarm detection

  • Detection program

  • Motion detection area 1x1, 2x2, 3x2, 3x3, 4x3, 4x4, 8x8, 16x16, 22x18

  • People/vehicle detection alert: audio alert with custom mp3 audio files



Storage

  • Built-in memory: Built-in memory card slot, supports microSD/SDHC/SDXC cards up to 256 GB

  • Overwrite

  • Maximum re-encoding time per file 1, 2, 3, 5, 10, 20 and 30 configurable minutes

  • Recording schedule



Network

  • LAN port RJ45 connector x 1/4KV surge-proof

  • Ethernet LAN speed based on T from 100 Mbps

  • Supported protocols HTTP/RTSP/FTP/SMTP/DHCP/NTP/NFS/RTMP

  • Compatible with ONVIF Compatible with Onvif 17.06

  • Number of online users: 6



Minimum web browsing requirements

  • Intel core i3 or higher or AMD equivalent

  • 2 GB RAM

  • AGP graphics card, Direct Draw, 32 MB RAM

  • Windows 10, Windows 8, Windows 7, DirectX 9.0 or later

  • Internet Explorer 6 and later (recommended), Microsoft Edge and Google Chrome



Package contents

  • IP Bullet IR Camera IC-DGM8109

  • User manual

  • Brand
  • Reference
    IC-DGM8109
  • In stock
    4 Items
  • EAN13
    4713218634863
