Name: Audio extractor 4 K - Techly NP IDATA HDMI-EAC
Brand: TECHLY NP
SKU: IDATA HDMI-EAC
Price: 77.45 EUR
Availability: InStock

€77.45

Tax included

HDMI Techly NP IDATA HDMI-EAC audio extractor, audio and video separation from 4 K source. Supports HDMI 2.0 , HDCP 2.2 / 1.4 , HDR, ARC and resolution up to 4 Kx 2 K@ 60 Hz. SPDIF, coaxial and audio outputs 3.5 mm.

Return policy

Delivery policy

Direct contact for info

Secure Payment

The HDMI-EAC IDATA allows you to separate the signal of a source in ultra-high definition and obtain a high quality video signal and an audio signal. The così separate audio signal is sent to the amplifier via SPDIF port, coaxial or audio port 3.5 mm L/R.

Features

Separates the audio signal from the HDMI and provides it separately
Converts an HDMI input to an HDMI Video + Audio output (SPDIF+R/L+COAXIAL)
Supports HDMI 2.0 , HDCP 2.2 , HDCP 1.4
Supports conversion from HDCP 1.4 to HDCP 2.2 , HDCP 2.2 to HDCP 1.4
Supports 3 D video format
Supports ARC function
Support HDR
Supports resolution up to 4 Kx 2 K@ 60 Hz UltraHD
Supports YUV 4 : 2 : 0 / 4 : 2 : 2 / 4 : 4 : 4 and RGB 4 : 4 : 4
Transmission without signal loss
Plug and Play, simple installation

Technical specifications

HDMI 2.0 Conforms
HDCP Conforms: HDCP 2.2 , HDCP 1.4
Supported HDMI resolution: 480 i/ 480 p/ 576 i/ 576 p/ 1080 i/ 1080 p@ 60 Hz/ 4 Kx 2 K@ 24 / 25 / 30 / 60 Hz
Supported audio formats: Dolby, DTS, LPCM
Maximum transfer speed: 18 Gbps
HDMI input cable distance: ≤ 5 m (AWG 24)
Output HDMI cable distance: ≤ 5 m (AWG 24)

Power supply
