- Compliant with MSA for compatibility with major switch manufacturers such as Cisco, Intellinet Network Solutions, ZyXEL, TP-Link, Ubiquiti and others (see specifications)
- Data transfer speed: 10 Gbps
- One LC duplex port in multimode fiber 10GBase-SR
- Fiber supported distance: up to 300m
- Wavelength: 850 nm
- Equivalent to Cisco SFP-10G-SR transceiver
- Standard SFP+ form factor
- Supports Digital Diagnostic Monitoring (DDM)
- Wide operating temperature: -40 - 75 °C
- Reduced electromagnetic interference thanks to metal housing
- Supports hot-plugging
Standard- IEEE 802.3z (Gigabit Fiber Optic)
- IEEE 802.3ae (Fiber optic 10 Gigabit Ethernet)
General information- Supports multimode fiber optic 10GBase-SR
- Connector: LC duplex fiber port
- Distance:
- 300m with 50/125 µm cable on 2000 MHz-km
- 33m with 62.5/125 µm cable over 200 MHz-km
- Wavelength: 850 nm
- Fiber optic power:
- Maximum TX power: -1 dB
- Minimum TX power: -6 dB
- Sensitivity: -10 dB
- Power budget: 4 dB
- Design: SFP+ (enhanced small form-factor pluggable)
- SFF-8472 Diagnostic Monitoring Interface for Optical Transceivers
- Certifications: FCC Class B, CE, RoHS
Power- Required power: 3.3 V
- Power consumption: 1.0 Watt (maximum)
Physical information- Dimensions (L x W x H): 57 x 14 x 12 mm
- Weight: 20 g
Environmental- Storage temperature: -40 to 85°C
- Operating temperature: -40 to 75°C
- Operating humidity: 5 – 95% RH, non-condensing
Package contents- SFP + industrial fiber optical transceiver module 10 Gigabit
