Switch KVM over IP 4 K DisplayPort Single Door Shared Access - Aten IDATA CN- 9950

Protect your new normalità with a hack-proof direct connection

IDATA CN- 9950 provides capabilities à over-IP for remote access to a dedicated PC/server via a direct network connection at BIOS level, hack-proof, and expands previous models with greater visual excellence, up to 4 K DCI resolution, using a FPGA graphics processor. It allows secure remote access to virtual audio, video and media, facilitating instant sharing of files and system updates on the network without the need to install or configure extra software.



The KVM over-IP IDATA CN- 9950 è switch ideal for global organizations and companies with different branches foruch´ creates a bridge between local and remote workplaces with a simple connection without any limitation or loss of productivityà. It is a practical and safe solution that helps companies during inactivityà or global crises.



Remote access protected, anywhere

The CN 9950 offers a direct BIOS-level connection to dedicated PCs/servers to allow immediate remote access from different locations without requiring the installation or configuration of additional software.



Double redundancy LAN/Power supply

The CN 9950 è with double connectivityà LAN/power that strengthens the reliabilityà of the system maintaining uninterrupted operations during any eventualityà. The power connectors are blocked with screws that guarantee a solid power failure, while è can easily identify the state of power via LED indicators.



Virtual media support for system updates

The CN 9950 allows authorized virtual media support to run file applications and software installations over the network, è particularly useful for diagnosis and resolution of network and BIOS problems, as well as running updates and software patches to keep the system up-to-date.



Connectivityà DI and relay; for emergency approach

The CN 9950 has an integrated 5 -pin thermal control for a DI input connection for system alarms (from a thermometer, humidity sensorà/port), as well as a relay terminal; for the virtual ignition function that reboots a locked or crashed PC/server remotely to ensure the availabilityà system for important applications.



Remote hacker-proof access solution in action

Unlike third-party solutions, such as the RDP (Remote Desktop Protocol) and the VNC (Virtual Network Computing), the KVM over IP switch does not require any additional driver/software and è capable of operating independently of a functional operating system when the PC/server è in its status at BIOS level. KVM access to the PC/server is based on a direct connection with keyboard, video and mouse, while communication between the PC/server and remote è workstation securely strengthened by encryption. This remote access path, based on hacker-proof hardware, è separated from the operating network to maintain safe data and workflow from one end to the other. In addition, allows the PC/server to remotely run system restart and install software updates in case of emergency. So, there are no risks of any third-party solutions, such as the RDP (Remote Desktop Protocol) and the VNC (Virtual Network Computing) solutions, the KVM over IP switch does not require any other than the PC/server. Data loss, backdoors, or any other form of computer attack, which instead a simple software solution can not è guarantee.



Technical specifications

• Console connections (local/remote): 1


• Number of computers: 1


• Computer Interface: USB, DisplayPort


• Console interface: USB, DisplayPort


• Maximum resolution: 4096 x 2160 @ 30 Hz


• Multiplatform support: Windows, Mac, Sun, Linux


• Audio: speaker, microphone



Dimensions

• Width: 20.00 cm


• Depthà: 14.93 cm


• Height: 2.85 cm



Package contents

• 1 x switch KVM over IP DisplayPort 4 K CN 9950


• 1 x DisplayPort cable


• 1 x USB cable (from USB-A to USB-B)


• 1 x USB cable (from USB-A to Mini-USB)


• 1 x power supply


• 1 x control terminal unit


• 1 x mounting kit


• 1 x set of feet


• 1 x user instructions
